Products INTEGRA Metering

tech preview

Designs in Pt 100 and Pt 500
2-wire cable with 2.5 m length, or 4-wire cable with 10 m length
Approval 2004/22/EC (MID - heat) and PTB K 7.2 (cold measurement)

Temperature sensors PSC

Cable sensors Pt100/Pt500 in 2- or 4-wire technology for installation in immersion sleeves

tech preview

Transformation from wireless M-Bus (EN 13757-4 / OMS 4.0) to wired M-Bus (EN 13757-3)
For water, heat, cooling, gas and electricity meters
M-Bus output to allow direct connection to a central office
Internal receiver aerial
Compliant OMS 4.0 and individual keys management

AMBILL® smart link II

Wireless M-Bus Converter

tech preview

In combination with cold water meters aquabasic® PMK and warm water meters TOPAS PMW-basic
M-Bus Protocol compliant with EN 13757-2/3
Open-Collector pulse output fully configurable
Protection indice IP 68
Battery powered up to 16 years of lifetime

aquastream® M-Bus/Pulses

Communication module system with dual interfaces M-Bus and Pulses

RUBIN WP-MF

Hydrant meter DN 80

RUBIN HYZ RS

Woltman hydrant meter DN 40
Model with check valve, Storz coupling and handgrip

RUBIN HYZ ST

Woltman hydrant meter DN 40 Model with system separator, Storz coupling and handgrip

RUBIN HYZ

Woltman hydrant meter DN 40

tech preview

Unique free-flow technology for AMR & AMI applications
Residential meter DN 15 - 50
Integrated radio communication: wireless M-Bus 868 & 434 MHz
Integrated wired M-Bus communication
Broad flow range (R500) --> capture usage at low water flows

TOPAS SONIC

Ultrasonic free-flow residential cold water meter

tech preview

Unique free-flow design - no mechanical wearing on metrology
Bulk meter DN 50 - 200
Highest robustness and resistance in harsh environments
Broad flow range (R 500), enabling low flow revenue
For Smart Metering applications in the utility market and for Irrigation applications

RUBIN SONIC

Ultrasonic bulk meter for cold water networks

tech preview

DN25...1200, PN16
TFluid = -20 - 150 °C (depending on coating type)
No moving parts
Low pressure loss
Approval: EN 1434 and PTB K7.2

AMFLO® MAG Pro

Electromagnetic flowmeter for measuring energy
in industrial and commercial buildings

tech preview

For energy measurement in heating and/or air-conditioning systems
10+1 year battery power (replaceable)
Installation as desired (vertical/horizontal)
Metrological approval according to 2014/32/EU (MID) and PTB K 7.2
With M-Bus interface or wireless M-Bus (radio) interface according to WHO standard

AMTRON® S3U

Compact energy meter for apartments

tech preview

For energy measurement in heating and/or air-conditioning systems
10+1 year battery power (replaceable)
Installation as desired (vertical/horizontal)
Metrological approval according to 2014/32/EU (MID) and PTB K 7.2
With M-Bus interface or wireless M-Bus (radio) interface according to WHO standard

AMTRON® S3 / S3+

Compact energy meter for apartments

tech preview

DN15 - 100
TFluid = 5 - 130/150 °C / TAmb = 5 - 50 °C
Homologations according to EN1434 and MID class 2 and 3
Measuring pipe in steel brass (DN 15 - 40) and grey steel (DN 50 - 100)

AMTRON® SONIC D

Compact energy meter for building automation

tech preview

Compatible with aquabasic® PMK and TOPAS PMW-basic
Wireless M-Bus Protocol compliant with EN 13757-4
868 MHz / T1 mode / OMS Version 4
Battery powered up to 16 years of lifetime
Programming with local NFC interface

aquastream® Radio

Communication Radio module system for water mechanical meters

tech preview

For cold water meters aquabasic® PMK and warm water meters TOPAS PMW-basic
M-Bus Protocol compliant with EN 13757-2/3
Protection index IP 68
Battery powered up to 16 years of lifetime
Programming with local NFC interface

aquastream® M-Bus

Communication M-Bus module system for water mechanical meters

tech preview

For economical, reliable remote reading of M-Bus meters at a central location using a modem
M-Bus level converter with USB interface
Safe from short-circuits and over-voltage
Integral M-Bus voltage supply (up to 32 M-Bus slaves)

M-Bus Mini-Master

M-Bus level converter

tech preview

Plug-in computer module
Interfaces to building management systems: M-Bus, LON, Modbus, N2Open, BACnet MS/TP, KNX
Sliding data for standard refrigerants
Integrated power supply for flowmeters
Metrological approval according to 2014/32/EU (MID) and PTB K7.2 (cold, hot/cold combined)

CALEC® ST II

Multi-functional thermal energy calculator for district heating and building technology

tech preview

Multi-function display with plain text and selectable language (D, E, F, I)
Medium temperature -50...550°C (approval 1...200°C)
Temperature difference 0...190K (approval 3...199K)
Integrated power supply for flowmeters
Metrological approval according to 2014/32/EU (MID) and PTB K7.2 (cold, hot/cold combined)

CALEC® energy master

Multi functional thermal energy calculator for district heating and building technology

tech preview

DN 20 - 40
PN 40 (flange); PN 16 (thread)
TFluid = 1 - 130 °C / TAmb = 5 - 55 °C
Measuring tube made of stainless steel (type 1.4404/316(L)) Stainless steel flange (type 1.4307/304L or 1.4404/316)
Approval according to MID 2014/32/EU

AMFLO® SONIC Smart

Ultrasonic flowmeter with integrated electronics for district heating and building automation

tech preview

DN 32 - 250
PN 16/25/40
TFluid = 1 - 130 °C / TAmb = 5 - 55 °C
Stainless steel measuring tube type 1.4404/316(L)
Approval according to MID 2004/22/EG (EN1434) and PTB TR K7.2 (Cold)

AMFLO® SONIC DryX

Ultrasonic flowmeter with an innovative replacement concept –
Extremely beneficial for district heating

tech preview

DN 15 - 100
PN 16 (versions with thread); PN 25 (version with flanges)
Approval according to MID 2004/22/EG (EN1434)
TFluid = 5 - 130/150 °C / TAmb = 5 - 55 °C
Measuring pipe in steel brass (DN 15 - 40) and grey steel (DN 50 - 100)

AMFLO® SONIC UFA-113

Compact ultrasonic flowmeter with integrated electronics for district heating and building automatisation

tech preview

DN 50 - 1200
No moving parts in the measuring tube
TFluid = 2 - 120°C (180 °C), TAmb = 0 - 60°C
Approvals according to EN 1434

AMFLO® SONIC UFA-280

Ultrasonic flowmeter for district heating and building automation

tech preview

DN 15 - 100
TFluid = 1 - 60 °C / TAmb = 5 - 55 °C (water or glycol water)
No moving parts
Low pressure loss
Approval: EN 1434 and PTB K7.2

AMFLO® MAG Smart

Compact magnetic flowmeter
in industrial and commercial buildings

tech preview

Domestic water meter DN 15 - 50
Temperature range 0.1 - 40 °C
Durable, robust mechanical meter with high measuring accuracy
Smart metering capability through modules aquastream®
Reliable Swiss precision product

aquabasic® PMK-basic

Multi-jet impeller meter for cold water

tech preview

Domestic water meter DN 20 - 40
Temperature range 0.1 - 40 °C
Durable, robust mechanical meter with high measuring accuracy
Smart metering capability through modules aquastream®
Reliable Swiss precision product

aquabasic® PMKF/-S

Multi-jet impeller meter for cold water

tech preview

Domestic water meter DN 20 - 25
Temperature range 0.1 - 40 °C
Durable, robust mechanical meter with high measuring accuracy and unique bayonet lock
Smart metering capability through module aquastream®
Reliable Swiss precision product

aquabasic® PMKB-basic

Multi-jet impeller meter for cold water / bayonet lock for horizontal & vertical installation

tech preview

Large water meter DN 40 - 300
Temperature range 0 - 50 °C
Turbine meter in dry-running version, enclosure protection IP 68
Can be retrofitted with non-reactive modules for remote readout
Measuring insert exchangeable

RUBIN KMS / KMS+

Mechanical bulk water meter for cold water

tech preview

Compound water meter DN 50 - 150
Temperature range 0 - 50°C
Turbine meter combined with annular piston meter
Can be retrofitted with non-reactive modules for remote reading
Multi-range measuring insert exchangeable without violation of the approval

RUBIN KTW / KTW+

Mechanical compound water meter for cold water

tech preview

M-Bus centre with integrated web server
For 20, 60, 120 or 250 M-Bus meters
Data logger with plug-in data memory
10/100 Base Ethernet
Transparent access to M-Bus

AMBUS® Link

Intelligent M-Bus data center for configuring, operating and monitoring M-Bus systems

tech preview

Pulse collector with M-Bus interface
Signal input with M-Bus interface
External power supply 12...18 V AC or 12...24 V DC
Configuration using AMBUS® Win software

AMBUS® IS

Pulse collector

tech preview

Pt100 sensors
DIN head for 4-wire connection
Approvals according to Directive 2004/22/EC (MID)
Approvals according to PTB K7.2 (cold measurement / combined cold and heat measurement)

Temperature sensors PLH

4-wire DIN head temperature sensors for pocket mounting

tech preview

Pt100 or Pt500 sensors
2-wire connection with 2.5 m fixed cable
Approvals according to Directive 2004/22/EC (MID)
Approvals according to PTB K7.2 (cold measurement / combined cold and heat measurement)

Temperature sensors DS/PSC

2-wire cable temperature sensors for direct immersion or immersion in a thermowell

Did not find your product?
